LABORATORY OF MATERIAL INVESTIGATION

Laboratory of material investigation.

Main task: investigation of physical and mechanical properties of materials and their joints.

Sector of sampmles preparation

Vacuum casting of Cu and its alloys onto stainless steel Vacuum casting of Cu and its alloys onto stainless steel
Sector of sampmles preparation

1.Cutting machine STRUERS Labotom-3

2.Grinding and polishing machine STRUERS TegraPol-11

3.Electropolishing and etching machine STRUERS LectroPol-5

4.Ultrasonic washer Struers Metason 120 T

5.Ultrasonic washer Struers Metason 200 HT with heating up to 60 oC

6.Drying box for the samples Struers Drybox-2.

Temperature range 40 - 90 oC

7.Inverted microscope OLYMPUS GX41 for checking of surface quality. Magnification range from х50 to х1000.

Metallography

Scanning electron microscope JEOL JSM-6510LV.
Scanning electron microscope JEOL JSM-6510LV.

Scanning electron microscope JEOL JSM-6510LV.

Accelerating voltage 0,5кV - 30 кV

Magnification range х5 - х300 000

Maximum size of sample diameter 150 mm, heght 48 mm

Silicon drift detector SiriusSD for the elemental microanalysis..

Inverted microscope OLYMPUS GX51. Magnification range from х12.5 to х1500.
Inverted microscope OLYMPUS GX51. Magnification range from х12.5 to х1500.

Stereomicroscope OLYMPUS SZX 16. Magnification range from х7 до х115.
Stereomicroscope OLYMPUS SZX 16. Magnification range from х7 до х115.

Mechanical testing

Hardness meters Wolpert Wilson 3000 BLD Brinell and Wolpert Wilson Rockwell
Hardness meters Wolpert Wilson 3000 BLD Brinell and Wolpert Wilson Rockwell

Mechanical testing machine INSTRON 3369
Mechanical testing machine INSTRON 3369

Mechanical testing

Spectral analyzer of chemical composition BELEC Vario Lab
Spectral analyzer of chemical composition BELEC Vario Lab
